PDB 80A
80A Power Distribution Board
80A continuous current with sensor
Compatible with Quadcopters and Hexacopters
Built-in hall-effect sensor for accurate telemetry
Supports input voltage up to 30V (6S)
Distributes power to up to 6 ESCs via solder pads
Regulated outputs: 5V/4A, 12V/4A, 3.3V/1.5A
Designed and made in India
Compatible with Quadcopters and Hexacopters
Built-in hall-effect sensor for accurate telemetry
Supports input voltage up to 30V (6S)
Distributes power to up to 6 ESCs via solder pads
Regulated outputs: 5V/4A, 12V/4A, 3.3V/1.5A
Designed and made in India
$70.99
QTY
Product Details
PDB 80A Power Distribution Board for Drones & High-Power Electronics
The axldrone PDB 80A is a compact and reliable power distribution board designed for efficient power delivery across drones, robotics, and electric mobility systems. With up to 80A current handling and 6S battery support, it delivers stable, clean power to multiple components without clutter.
Commonly used as a drone power distribution board, it is also ideal for ground-based applications like rovers and electric vehicles, making it a versatile choice for modern builds. The board supports up to 6 ESCs or devices, ensuring organized and efficient power routing in multi-component systems.
Built-in voltage and current sensors provide real-time system monitoring, helping improve safety and performance. Its compact design and durable FR4 construction make it perfect for tight integrations and long-term use.
Key Features & Specifications
Handles continuous current loads up to 80 A with stable performance.
Compatible with quadcopter, hexacopter configurations.
Supports wide input voltage up to 30 V (6S) for flexible battery configurations.
Distributes power efficiently to up to 6 ESCs through dedicated solder pads.
Provides regulated outputs of 5 V @ 4 A, 12 V @ 4 A, and 3.3 V @ 1.5 A for onboard electronics.
Built-in hall-effect current sensor delivers accurate current and voltage telemetry.
Constructed on high-density FR4 PCB for superior durability and heat resistance.
Lightweight and compact layout optimized for drone integration.
Designed for easy soldering with clearly labeled and well-spaced connection pads.
Efficient copper trace design for improved thermal management and reliability.
Designed and manufactured entirely in India with rigorous quality control.
Mechanical Size: 56 mm × 54 mm × 7.5 mm
Mounting Hole: M3 (four mounting holes)
Weight: 18 g
PCB Material: High-density FR4
Input Voltage Range: Up to 30 V (supports up to 6S LiPo)
Maximum Current Handling: Up to 80 A
Number of Output Channels: Supports up to 6 ESCs (six +/− power pads)
Integrated Voltage Regulators (DC-DC / BECs): 5 V / 4 A, 12 V / 4 A, 3.3 V / 1.5 A
Power Connector: JST 6-pin power connector (5V, 5V, CURRENT, VOLTAGE, GND, GND)
Sensors: Integrated Hall-effect current sensor and voltage sensing for monitoring/telemetry
Country of Manufacture: 100% Made in India
Designed For:
Quadcopters
Hexacopters
Rovers
Electric cycles
Electric skateboards
Package Includes:
1 × Power Distribution Board 80A
1 × 220 µF/50 V capacitor
