axl EL95
UHF RFID Antenna
Linearly polarized patch antenna technology
Hemispherical radiation pattern with 90° beamwidth
Peak gain of 4.5 dBiC for dependable read performance
Edge-mount SMA connector for embedded integration
Optimized for the FCC 902–928 MHz frequency band
$47.99
QTY
Product Details
The AXL EL 95 is a UHF RFID antenna designed for operation in the FCC 902–928 MHz frequency band, utilizing advanced patch antenna technology to deliver reliable wide-area coverage. It produces a hemispherical radiation pattern with 90° beamwidth in both elevation and azimuth, enabling consistent tag detection across broad zones.
This antenna provides a typical gain of 1.4 dBiC and a peak gain of 4.5 dBiC, supporting dependable read performance in demanding environments. It features linear polarization (LP), with axial ratios of 15 dB at boresight and 20 dB within the 3 dB beamwidth, ensuring stable readability across varying tag orientations.
Electrical performance includes a VSWR of less than 2.0:1 and a standard 50 Ω input impedance, allowing efficient power transfer and minimal signal reflection. A front-to-back ratio below -15 dB helps reduce rear radiation and improve forward
directivity.
For integration, the AXL EL 95 is equipped exclusively with an edge-mount SMA connector, supporting straightforward implementation in embedded RFID systems
Key Specifications
Antenna Type: Patch Antenna
Operating Frequency: FCC 902-928 MHz
Polarization: Linear - Vertical
Gain: US version 1.4 dBiC (Typical), 4.5 dBiC (Max)
Peak Efficiency: 70%
Return Loss: <-4dB (Min), -20dB (Max)
Radiation Pattern – Vertical plane: Omni
Radiation Pattern – Horizontal plane: Directional
Input Impedance: 50Ω
Overall size: 60 x 60 x 8 mm
Weight: 50g
Product Variation with Connector Type FCC (902-928 MHz)
Edge Mount: AXL-EL95-EMSMA
